Horizontal Pallet Strapping Machine PS -713H


Please contact us for pricing and ordering information.

Description

Without doubt the best value horizontal pallet strapping machine available - simple robust design ensures reliable performance and ease of maintenance.

PSTP-713H is a fully automatic pallet strapping machine designed for horizontal strapping. It secures pallet loads and stacked boxes with PP or PET strapping. The PSTP-713H can accommodate a wide variety of products like bricks, fruits, cans, bottles, beverage, and many other kinds of palletized goods. It is easy to integrate TP-713H into the new or existing production lines. With the user friendly and state-of-the-art design, PSTP-713H pallet strapping machine helps maximize uptime for greater production efficiency and lower packaging cost.

Specification summary:

Features

  • PLC control and HMI
  • Index strapping head
  • Strap guide arm
  • Safety rack
  • Friction weld sealing technology
  • Adjustable sealing and cooling time
  • Stable arch movement
  • Reinforced dual-track-pillar system

Options

  • Floating Head
  • Free standing operation desk
  • Siemens PLC & HMI
  • Failure indicator
  • HMI on the opposite side
  • Lower tension 200 - 1200 N (20 - 120 kg)
  • Light tree alarm with low strap sensor (triple lamp)
  • Strap dispenser 90-degree turn

Technical Data

Strap Type  PP or PET straps
Strap Width  9 mm, 12 mm, or 15.5 mm
Capacity  Up to 60 pallets/hour (3 straps/pallet)
(depends on package dimensions)
Tension Range  1100 - 3000 N (standard)
  200 - 1200 N (optional)
Strap Core Size  406 mm
Minimum strapping height  (a) With conveyor: 160 mm above conveyor surface
(b) Without conveyor: 240 mm above floor
Net Weight  875 kg
Electrical Requirement  220V, 380V, 400V, 415V 50/60Hz 3PH



 Contact: The Plastic Strapping Company Ltd
